AS Side Mount Pool Sand Filters

Name: AS Side Mount Pool Sand Filters - Reliant Pool Products
SKU: S116S|S119S|S124S

SKU S116S|S119S|S124S Categories Sand Filters, Pool Filters

Reliant^® AS side mount sand filters are high-performance, totally corrosion-proof sand filters that blend superior flow characteristics and features with ease of operation. Efficient flow and balanced back washing are your professional choices for your pools.

FEATURES

The filter tank is constructed from HDPE.
The top diffuser ensures an even distribution of water over the top of the sand media bed. All internal Pipin is 1.5″ dia. (50mm) to provide smooth, free-flowing performance.
Bottom drain plug for easy winterization or maintenance.
Include 7 position multi-port valve.

BACKWASH – For Cleaning accumulated debris in the sand bed
RINSE – Use after finishing the backwash cycle to ensure dirty water is rinsed out of the filter to waste
WASTE – By-passes the filter for draining or lowering the pool water level and for vacuuming heavy debris directly to the waste line
RECIRCULATE – Water is recirculated through the valve, by-passing the filter
CLOSE – Shuts off the flow from the pump to the filter
FILTER – For normal filtering and regular vacuuming
WINTER – For ease of winterizing
